FAPT Ladder for PC Operators manual Page 308

Operators manual
FAPT LADDER OPERATOR’S
SUPPLEMENTARY MANUAL
(FOR PERSONAL COMPUTER)
01 98.06.22 Hanaoka Additioanl 3.5-inch FD version B-66131E/05-5
EDIT DATE DESIG.
DESCRIPTION
5/8
TITLE
DRAW.NO.
SHEET
CUST.
(Correct)
(1) CONFIG.SYS, AUTOEXEC.BAT
・・・・・・・・・・
(Note) Windows NT4.0 uses CONFIG.NT instead of CONFIG.SYS.
(2)Using EMS
・・・・・・・・・・
(Note) Above setting is not necessay for Windows NT4.0.
(Add after “2.2 Installation Procedure“)
Note 3) When you install the program of the system or module under Windows NT 4.0, you
must enter commands under a Command Prompt of a full screen of Windows NT 4.0.
The Command Prompt Window appears when you select the [Start] menu and choose
the [Command Prompt] from the [Programs]. If the Command Prompt Window is not
full screen display, press ALT+ENTER keys to switch to full screen display.
(Replace a part of “3 ACTIVATION“)
(Present)
(1) Activation method
[Operation]
① Activate FAPT LADDER with the following commands:
・・・・・・・・・・
(Note 1) Before starting up FAPT LADDER, change the current drive and current
directory to the drive and directory in which the system file exists . If FAPT
LADDER is started up with path designation, or by specifying different
directory as the current directory, FAPT LADDER may malfunction.
(Correct)
(1) Activation method
[Operation]
① Activate FAPT LADDER with the following commands:
・・・・・・・・・・
(Note 1) When you install the program of the system or module under Windows NT 4.0,
you must enter the commands under a Command Prompt of a full screen of
B: ＼>A:
A: ＼>CD ＼FLADDER
A: ＼FLADDER> FLADDER
(Note
)
B: ＼>A:
A: ＼>CD ＼FLADDER
A: ＼FLADDER> FLADDER
(Note 1) (Note 2)
