FAPT Ladder for PC Operators manual Page 307

Operators manual

Page of 311

/ 311

FAPT LADDER OPERATOR’S

SUPPLEMENTARY MANUAL

(FOR PERSONAL COMPUTER)

01 98.06.22 Hanaoka Additioanl 3.5-inch FD version B-66131E/05-5

EDIT DATE DESIG.

DESCRIPTION

4/8

TITLE

DRAW.NO.

SHEET

CUST.

LADDER” for personal computer. Refer to the “2. Applied Software” about kinds of

software of 3.5-inch FD version.

4. Working under a Command Prompt of a full screen of Windows NT4.0

(Replace “2.1 Operating Environment“)

2.1 Operating Envaironment

To use the software, the requirements indicated in the table below must be satisfied. Before

installing the software, check these requirements.

IBM PC/AT NEC PC9801

Conventional memory Free area of 500K bytes or more is required (Note1) (Note2).

Hard Disk About 3M bytes is required for installing the system (Note3).

OS ・PC-DOS Version 3.3 or later

・Windows95 (MS-DOS mode)

・Windows NT 4.0（Command

Prompt of full screen）

MS-DOS Version 3.1 or later

Printer EPSON VP1000 NEC PR201H

Epson VP1000（Note 4）

EMS A LIM type EMS (expanded memory specification) memory board

may be required depending on the PMC model and the size of a

sequence program to be created. For details, see 2.1.1.

Others The EGA graphic interface is

required

(Note 1) If the standerd memory size of the machine is insufficient, memory expansion is

required.

(Note 2) Even if the machine has 640K-byte memory, the memory may not be large enough

when an installed driver, for example, uses a large memory space. The size of free

space in conventional memory can be checked with the MS-DOS command CHKDSK.

(Note 3) In addition, an area for storing sequence program data is required.

(Note 4) To use the Epson VP1000 with an NEC PC9801, a setting file modification is required.

For details, see Section 1.2 in Part Ⅱ.

(Replace “2.1.2 IBM PC/AT operating environment“)

(Present)

(1) CONFIG.SYS, AUTOEXEC.BAT

・・・・・・・・・・

(2)Using EMS

・・・・・・・・・・

Contents Summary of FAPT Ladder for PC Operators manual
