FAPT Ladder for PC Operators manual Page 309

Operators manual

Page of 311

/ 311

FAPT LADDER OPERATOR’S

SUPPLEMENTARY MANUAL

(FOR PERSONAL COMPUTER)

01 98.06.22 Hanaoka Additioanl 3.5-inch FD version B-66131E/05-5

EDIT DATE DESIG.

DESCRIPTION

6/8

TITLE

DRAW.NO.

SHEET

CUST.

Windows NT 4.0. The Command Prompt Window appears when you select the

[Start] menu and choose the [Command Prompt] from the [Programs]. If the

Command Prompt Window is not in full screen display mode, press ALT+ENTER

keys to switch to full screen display.

(Note 2) Before starting up FAPT LADDER, change the current drive and current

directory to the drive and directory in which the system file exists. If FAPT

LADDER is started up with path designation, or by specifying different directory

as the current directory, FAPT LADDER may malfunction.

5. Software Version Table

(Replace a part of “APPNDIX 9 SOFTWARE VERSION TABLE”)

・Combination of diverse system floppy disks (1)

Software -JXXX Combinations of versions

PMC-SA/SB/SC/NB

/PA/QC

502

－

01.0

－02.0

03.0

－03.6

04.0

－06.0

PMC-N/NA 501

－

01.1

－02.3

03.0

－03.1

－

04.0

－04.8

－

PMC-L/M/P 500 01.1

－01.12

02.0

－02.3

03.0

－

04.0

－04.8

－
