Series 0i/0i Mate - Model B Connection manual (Function) Page 1032

Connection manual (Function)
B–63833EN–1/02
A. INTERFACE BETWEEN CNC AND PMC
1014
f : Available
– : Unavailable
Function
Signal name Symbol Address
T
series
M
series
Section
Power Mate background operation
signal
BGEN G092#4 f f
13.5
Power Mate read/write alarm signal BGIALM G092#3 f f
13.5
Power Mate read/write busy signal BGION G092#2 f f
13.5
Slave diagnosis selection signal EDGN F177#7 f f
13.5
Slave parameter selection signal EPARM F177#6 f f
13.5
Slave program selection signal EPRG F177#4 f f
13.5
Slave external read start signal ERDIO F177#1 f f
13.5
Slave read/write stop signal ESTPIO F177#2 f f
13.5
Slave macro variable selection signal EVAR F177#5 f f
13.5
Slave external write start signal EWTIO F177#3 f f
13.5
Data input/output
External read start signal EXRD G058#1 f f
13.5,
13.3
with I/O Link
External read/punch stop signal EXSTP G058#2 f f
13.5,
13.3
External punch start signal EXWT G058#3 f f
13.5,
13.3
I/O Link check signal IOLACK G092#0 f f
13.5
Slave I/O Link selection signal IOLINK F177#0 f f
13.5
I/O Link specification signal IOLS G092#1 f f
13.5
Read/punch alarm signal RPALM F053#3 f f
13.5,
13.3
Read/punch busy signal PRBSY F053#2 f f
13.5,
13.3
Group number specification signals SRLNI0 to SRLNI3 G091#0 to #3 f f
13.5
Group number output signals SRLNO0 to SRLNO3 F178#0 to #3 f f
13.5
External read start signal EXRD G058#1 f f
External punch start signal EXWT G058#3 f f
External I/O device
External read/punch stop signal EXSTP G058#2 f f
External I/O device
control
Background editing signal BGEACT F053#4 f f
13.3
Read/punch busy signal RPBSY F053#2 f f
Read/punch alarm signal RPALM F053#3 f f
Alarm signal AL F001#0 f f
Alarm signal
Battery alarm signal BAL F001#2 f f
2.4
A.2
SIGNAL SUMMARY
A.2.1
Signal Summary
(In Order of Functions)
