Series 0i/0i Mate - Model B Connection manual (Function) Page 393
Connection manual (Function)
B–63833EN–1/02
7. FEEDRATE CONTROL/ACCELERATION
AND DECELERATION CONTROL
375
NOTE
1 If an axis for which a reference position is established and
an axis for which no reference position is established are
simultaneously specified with G28 when bit 2 (ALZ) of
parameter No. 7055 is set to 1, G28 is executed after turning
off the AI advanced preview control mode, regardless of the
setting of bit 3 (AZR) of parameter No. 7054.
2 If the serial spindle is switched to the Cs contour control
mode then G00 is specified for the Cs contour control axis
without performing a reference position return operation
even once during AI advanced preview control when bit 1
(NRF) of parameter No. 3700 is set to 0, a P/S alarm (No.
090) is issued, regardless of the setting of bit 2 (ALZ) of
parameter No. 7055.
ADP Single direction positioning in the AI advanced preview control mode is
executed:
0 : In the normal mode.
1 : In the AI advanced preview control mode.
(1) Parameters related to linear acceleration/deceleration before
interpolation
Parameter No.
Parameter Standard
mode
Advanced
preview
control
AI advanced
preview
control
Parameter 1 for setting accel-
eration
None 1770
Parameter 2 for setting accel-
eration
None 1771
Speed when overtravel alarm
is issued
None 1784
D Parameter numbers in
standard mode,
advanced preview
control mode, and AI
advanced preview
control mode
