Series 0i/0i Mate - Model B Connection manual (Function) Page 769
Connection manual (Function)
B–63833EN–1/02
12. DISPLAY/SET/EDIT
751
#7
3207
#6 #5 #4 #3 #2 #1 #0
OM4
[Data type] Bit
OM4 A message displayed on the external operator message screen can have:
0 : Up to 256 characters, and just a single message can be displayed.
1 : Up to 64 characters, and up to four messages can be displayed.
OPERATOR’S MANUAL
(M series) (B–63844EN)
III.11.7.1
External operator message log-
ging and display
Series 0i–B
OPERATOR’S MANUAL
(T series) (B–63834EN)
III.11.7.1
External operator message log-
ging and display
OPERATOR’S MANUAL
(M series) (B–63864EN)
III.11.7.1
External operator message log-
ging and display
Series 0i Mate–B
OPERATOR’S MANUAL
(T series) (B–63854EN)
III.11.7.1
External operator message log-
ging and display
Displaying the same characters in the same positions on the screen causes
a LCD to degrade relatively quickly. To help prevent this, the screen can
be cleared by pressing specific keys. It is also possible to specify the
automatic clearing of the screen if no keys are pressed during a period
specified by a parameter.
However, it is disabled for the open CNC.
Holding down the
CAN
key and pressing a function key clears the screen.
Hold down the
CAN
key and press a function key (such as
POS
and
PROG
).
Press a function key, to restore the display.
The CNC screen is automatically cleared if no keys are pressed during the
period (in minutes) specified by parameter (No. 3123). The screen is
restored by pressing any key.
Reference item
12.1.18
Erase Screen
Display/Automatic
Erase Screen Display
General
Erase screen display
Automatic erase screen
display
