Series 0i/0i Mate - Model B Connection manual (Function) Page 1060

Connection manual (Function)
B–63833EN–1/02
A. INTERFACE BETWEEN CNC AND PMC
1042
Group
Referen
ce item
M
series
T
series
Address Signal nameSymbol
SIND G033#7 f f
SIND2 Spindle motor speed command select signal G035#7 f f 15.4
SIND3 G037#7 f f
Skip signal X004#7 f f 14.3.1
SKIP
Overload torque signal X004#7 – f 11.13
SKIP2 to SKIP6,
SKIP7,SKIP8
Skip signal
X004#2 to #6,
#0,#1
f f 14.3.3
SKIPP Skip signal G006#6 f – 14.3.1
SLVA G073#1 f f
SLVB
Slave operation command signal (serial spindle)
G077#1 f f
SLVSA F046#4 f f
9.2
SLVSB
Slave operation status signal (serial spindle)
F050#4 f f
SMZ Error detect signal G053#6 f – 7.2.4.3
SOCNA
/
G071#4 f f
SOCNB
Soft start
/
stop cancel signal (serial spindle)
G075#4 f f
9.2
SOR Spindle orientationsignal G029#5 f f
SOV0 to SOV7 Spindle speed override signal G030 f f
9.3
SPAL Spindle fluctuationdetection alarm signal F035#0 f f 9.5
S
SPL Feed hold lamp signal F000#4 f f 5.1
SPO Software operator's panel signal(*SP) F075#7 f f 12.1.14
SPPHS Spindle phase synchronous control signal G038#3 f f 9.11
SPSLA G071#2 f f
SPSLB
Spindle select signal (serial spindle)
G075#2 f f
9.2
SPSTP Spindle stop complete signal G028#6 f – 9.7
SPSYC Spindle synchronous control signal G038#2 f f 9.11
SRLNI0 to SRLNI3 Group number specification signals G091#0 to #3 f f
SRLNO0 to SRLNO3 Group number output signals F178#0 to #3 f f
13.5
SRN Program restart signal G006#0 f f
SRNMV Program restart under way signal F002#4 f f
5.7
SRVA G070#4 f f
SRVB
CCW command signal (serial spindle)
G074#4 f f
9.2
SSIN G033#6 f f
SSIN2 Spindle motor command polarity select signal G035#6 f f 15.4
SSIN3 G037#6 f f
SSTA F045#1 f f
SSTB
Speed zero signal (serial spindle)
F049#1 f f
9.2
