Series 0i/0i Mate - Model B Connection manual (Function) Page 1037
Connection manual (Function)
B–63833EN–1/02
A. INTERFACE BETWEEN CNC AND PMC
1019
Function Section
M
series
T
series
AddressSymbolSignal name
Soft start/stop cancel signals
SOCNA G071#4 f f
Soft start/stop cancel signals
(serial spindle)
SOCNB G075#4 f f
INTGA G071#5 f f
Speed integral signals (serial spindle)
INTGB G075#5 f f
Output switch request signals
RSLA G071#6 f f
Output switch request signals
(serial spindle)
RSLB G075#6 f f
Power line status check signals
RCHA G071#7 f f
Power line status check signals
(serial spindle)
RCHB G075#7 f f
Orientation stop position change
INDXA G072#0 f f
Orientation stop position change
command signals (serial spindle)
INDXB G076#0 f f
Rotational direction command signals ROTAA G072#1 f f
for orientation stop position change
(serial spindle)
ROTAB G076#1 f f
Shortcut command signals for NRROA G072#2 f f
orientation stop position change
(serial spindle)
NRROB G076#2 f f
Differential speed mode command
DEFMDA G072#3 f f
Differential speed mode command
signals (serial spindle)
DEFMDB G076#3 f f
OVRA G072#4 f f
Analog override signals (serial spindle)
OVRB G076#4 f f
Spindle serial
output/spindle
Incremental command externally set
INCMDA G072#5 f f
9.2
output/spindle
analog output
Incremental command externally set
orientation signals (serial spindle)
INCMDB G076#5 f f
9.2
Spindle switch MAIN MCC contact
MFNHGA G072#6 f f
Spindle switch MAIN MCC contact
status signals (serial spindle)
MFNHGB G076#6 f f
Spindle switch HIGH MCC contact
RCHHGA G072#7 f f
Spindle switch HIGH MCC contact
status signals (serial spindle)
RCHHGB G076#7 f f
Magnetic sensor orientation command
MORCMA G073#0 f f
Magnetic sensor orientation command
signals (serial spindle)
MORCMB G077#0 f f
Subordinate operation mode command
SLVA G073#1 f f
Subordinate operation mode command
signals (serial spindle)
SLVB G077#1 f f
Motor power cutoff command signals
MPOFA G073#2 f f
Motor power cutoff command signals
(serial spindle)
MPOFB G077#2 f f
DSCNA G073#4 f f
Disconnection detection disbale signal
DSCNB G077#4 f f
ALMA F045#0 f f
Alarm signals (serial spindle)
ALMB F049#0 f f
SSTA F045#1 f f
Speed zero signals (serial spindle)
SSTB F049#1 f f
SDTA F045#2 f f
Speed detection signals (serial spindle)
SDTB F049#2 f f
