5314 Positional deviation limit imposed during tapping axis movement in rigid tapping
[Data type] 2–word
[Unit of data] Detection unit
[Valid data range] 0 to 99999999
Usually, parameter No.5310 is used to set a positional deviation limit
imposed during tapping axis movement in rigid tapping. However,
parameter No.5314 can be used to set a value greater than the valid data
range of parameter No.5310 because of the resolution of the detector
being used.
NOTE
1 When parameter No.5314 is set to 0, the setting of
parameter No.5310 is used. When parameter No.5314 is
set to a value other than 0, parameter No.5310 is disabled;
in this case, the setting of parameter No.5314 is used.
2 When rigid tapping is performed using the second spindle
• When the SPR parameter (bit 1 of parameter No.5204)
is set to 0, the setting of parameter No.5314 (or No.5310)
is applied to the second spindle, as well as to the first
spindle.
• When the SPR parameter (bit 1 of parameter No.5204)
is set to 1, the settings of parameter No.5350 is applied
to the second spindle.
5321
Spindle backlash in rigid tapping (first–stage gear)
Spindle backlash in rigid tapping
5322
Spindle backlash in rigid tapping (second–stage gear)
5323
Spindle backlash in rigid tapping (third–stage gear)
5324
Spindle backlash in rigid tapping (fourth–stage gear)
5325
Spindle backlash in rigid tapping using the second spindle (first–stage gear)
Spindle backlash in rigid tapping using the second spindle
5326
Spindle backlash in rigid tapping using the second spindle (second–stage gear)
[Data type] Byte
[Unit of data] Detection unit
[Valid data range] 0 to 127
Each of these parameters is used to set a spindle backlash.
