8. AUXILIARY FUNCTION
B–63833EN–1/02
422
[Operation] Refer to the description of the output conditions and procedure described
in “basic procedure.”
[Classification] Input signal
[Function] Indicates that the external operation function has been completed for the
high–speed M, S, T, or B interface.
[Operation] The “basic procedure” describes the procedure and operation of the
control unit when the signal is set to 1 or 0.
#7
G004
#6 #5
MFIN3
#4
MFIN2
#3 #2 #1 #0
BFING005 BFIN TFIN SFIN EFIN MFIN
#7
F007
#6 #5 #4 #3 #2 #1
EFD
#0
#7
MHI3001
#6 #5 #4 #3 #2 #1 #0
MHI Exchange of strobe and completion signals for the M, S, T, and B codes
0 : Normal
1 : High–speed
NOTE
1 The strobe signals MF, SF, TF, and BF are “0” when the
power is turned on.
2 When the control unit is reset, MF, SF, TF, and BF are set
to “0”.
8.1
Miscellaneous function/2nd auxiliary func-
tion
CONNECTION MANUAL
(This manual)
8.3 Multiple M commands in a block
11.7 External operation function
External operation
function completion
signal (M series) EFIN
<G005#1>
Signal address
Parameter
Note
Reference item
