Series 0i/0i Mate - Model B Connection manual (Function) Page 1048

Connection manual (Function)
B–63833EN–1/02
A. INTERFACE BETWEEN CNC AND PMC
1030
f : Available
– : Unavailable
Group
Symbol Signal name Address
T
series
M
series
Referen
ce item
*+ED1 to *+ED4 External deceleration signal G118 f f 7.1.8
*+L1 to *+L4 Overtravel signal G114 f f 2.3.1
*-ED1 to *-ED4 External deceleration signal G120 f f 7.1.8
*-L1 to *-L4 Overtravel signal G116 f f 2.3.1
*ABSM Manual absolute signal G006#2 f f 5.4
*BECLP B-axis clamp completion signal G038#7 – f 11.9
*BEUCP B-axis unclamp completion signal G038#6 – f 11.9
*BSL Block start interlock signal G008#3 f f 2.5
*CRTOF Automatic erase CRT screen display cancel signal G062#1 f f 12.1.18
*CSL Cutting block start interlock signal G008#1 f f 2.5
*DEC1 to *DEC4 Deceleration signal for reference position return X009 f f 4.1
*EAXSL
Control axis selection status signal(PMC axis
control)
F129#7 f f 15.1
*ESP X008#4 f f
*ESP
Emergency stop signal
G008#4 f f
2.1
*ESPA G071#1 f f
*ESPB
Emergency stop signal (serial spindle)
G075#1 f f
9.2
*FLWU Follow-up signal G007#5 f f 1.2.6
* *FV0 to *FV7 Feedrate override signal G012 f f 7.1.6.2
*FV0E to *FV7E Feedrateoverride signal (PMC axis control) G151 f f 15.1
*FV0O to *FV7O Software operator's panel signal(*FV0 to *FV7) F078 f f 12.1.14
*HROV0 to *HROV6 1% step rapid traverse override signal G096#0 to #6 f f 7.1.6.1
*IT Interlock signal G008#0 f f 2.5
*IT1 to *IT4 Interlock signal for each axis G130 f f 2.5
*JV0 to *JV15 Manual feedrate override signal G010,G011 f f 3.1
*JV0O to *JV15O Software operator's panel signal(*JV0 to *JV15) F079,F080 f f 12.1.14
*PLSST Polygon spindle stop signal G038#0 f – 6.10.2
*SCPF Spindle clamp completionsignal G028#5 f – 9.7
*SP Feed hold signal G008#5 f f 5.1
*SSTP Spindlestop signal G029#6 f f 9.3
*SSTP1 G027#3 f f
*SSTP2 Individual spindle stop signals G027#4 f f 9.9
*SSTP3 G027#5 f f
*SUCPF Spindle unclamp completionsignal G028#4 f – 9.7
*TLV0 to *TLV9 Tool life count override signal
G049#0 to
G050#1
– f 10.3
A.2.2
List of Signals
(In Order of Symbols)
Previous page
Next page
