Series 0i/0i Mate - Model B Connection manual (Function) Page 742

Connection manual (Function)

Page of 1090

/ 1090

12. DISPLAY/SET/EDIT

B–63833EN–1/02

724

[Classification] Input signal

[Function] The CNC has an meter which is started by an input signal from the PMC.

Additionally, there are meters for counting the automatic operation time

and counting cutting time. The count for these meter can be displayed on

the screen. The count can be preset by the operator.

[Operation] When the signal is set to 1, the meter starts counting.

#7 #6 #5 #4 #3 #2 #1 #0

G053 TMRON

#7 #6 #5 #4 #3 #2 #1 #0

PRTSFF062

6700

#6 #5 #4 #3 #2 #1 #0

PCM

[Data type] Bit

PCM M code that counts the total number of machined parts and the number of

completed parts

0 : M02, or M30, or an M code specified by parameter No. 6710

1 : Use only the M code specified by parameter No. 6710 and not M02 or

M30

6710 M code that counts the total number of machined parts and the number of

completed parts

[Data type] Byte

[Valid data range] 0 to 255 except 98 and 99

The total number of machined parts and the number of completed parts

are counted (+1) when the M code set is executed.

NOTE

A value of 0 is invalid (the number of parts is not counted for

M00). Data 98 and 99 cannot be set.

General–purpose

integrating meter start

signal

TMRON <G053#0>

Signal address

Parameter
