B–63833EN–1/02

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

365

Name Description

Program restart f As an acceleration/deceleration time

constant for movement to a restart position,

the following parameters are used:

When exponential acceleration/decelera-

tion is used: Parameter No. 1624 and No.

1625

When linear/bell–shaped acceleration/de-

celeration is used: Parameter No. 1622. For

switching between the acceleration/decel-

eration types, bits 0 and 1 of parameter No.

1610 are used.

Return in rigid tapping

Macro executor (execution

macro)

MDI operation

Manual intervention

NOTE

1 For some functions to be specified, separate options need

to be set.

2 Those functions marked with an asterisk (*) do not perform

look–ahead control of multiple blocks.

Before G05.1 Q1, the following modal codes must be specified. If this

condition is not satisfied, P/S alarm No. 5111 will be issued.

G code Description

G00

G01

G02

G03

Positioning

Linear interpolation

Circular interpolation (CW)

Circular interpolation (CCW)

G13.1 Polar coordinate interpolation cancel mode

G15 Polar coordinate command cancel

G25 Spindle speed fluctuation detection off

G40 Cutter compensation cancel

G40.1 Normal direction control cancel mode

G49 Tool length compensation cancel

G50 Scaling cancel

G50.1 Programmable mirror image cancel

G64 Cutting mode

G67 Macro modal call cancel

G69 Coordinate rotation cancel

G80 Canned cycle cancel

G94 Feed per minute

G97 Constant surface speed control cancel

G160 In–feed control function cancel

Conditions for entering

AI advanced preview

control mode
