Series 0i/0i Mate - Model B Connection manual (Function) Page 951

Connection manual (Function)

Page of 1090

/ 1090

B–63833EN–1/02

15. PMC CONTROL FUNCTION

933

Substitution is possible for the No. of parts required and the No. of parts

machined.

BCD 4–digit code

(0000 to 9999)

Set to 110000.

0 : No. of parts required

1 : No. of parts machined

0/11 1 0 0 0 0

Address Data

MSB LSB

Value of aprt nos.

...

Data specification for No. of parts required and No. of

parts machined.

[Classification] Input signal

[Function] These signals indicate the entered data.

The use of the 16 code signals varies with the data type.

[Classification] Input signal

[Function] These signals indicate the type of the entered data.

[Classification] Input signal

[Function] The signal reports that the address and data are set in external data input.

When the signal is set to “1”, the control unit reads the address and data

for external data input.

[Operation] The “basic procedure” describes the procedure for, and operation of, the

control unit when the signal turns to “1”.

6) Substituting No. of

parts required and No.

of parts, machined

Signals

Data signals for external

data input ED0 to ED15

<G000, G001>

Address signals for

external data input

EA0 to EA6 <G002>

Read signal for external

data input ESTB

<G002#7>
