A. INTERFACE BETWEEN CNC AND PMC
1023
Function Section
M
series
T
series
AddressSymbolSignal name
Software operator’s panel signal
(HS1C)
HS1CO F077#2 f f
Software operator’s panel signal
(HS1D)
HS1DO F077#3 f f
Software operator’s panel signal
(MP1)
MP1O F076#0 f f
Software operator’s panel signal
(MP2)
MP2O F076#1 f f
Software operator’s panel signals (*JV0
to *JV15)
*JVO0 to *JV15O F079, F080 f f
Software operator’s panel signals
(*FV0 to *FV7)
*FV0O to *FV7O F078 f f
Software operator’s
panel
Software operator’s panel signal
(ROV1)
ROV1O F076#4 f f
12.1.14
Software operator’s panel signal
(ROV2)
ROV2O F076#5 f f
Software operator’s panel signal (BDT) BDTO F075#2 f f
Software operator’s panel signal (SBK) SBKO F075#3 f f
Software operator’s panel signal (MLK) MLKO F075#4 f f
Software operator’s panel signal (DRN) DRNO F075#5 f f
Software operator’s panel signals
(KEY1 to KEY4)
KEYO F075#6 f f
Software operator’s panel signal (*SP) SPO F075#7 f f
Software operator’s panel
general–purpose switch signals
OUT0 to OUT7 F072 f f
2nd reference position return
completion signals
ZP21 to ZP24 F096 f f
Second reference
position return/3rd,
4th reference
3rd reference position return
completion signals
ZP31 to ZP34 F098 f f
4.5
position return
4th reference position return
completion signals
ZP41 to ZP44 F100 f f
Multi–stage skip Skip signals
SKIP2 to SKIP6,
SKIP7, SKIP8
X004#2 to #6,
#0, #1
f f
14.3.3
Canned cycle (M
series)/multiple
repetitive turning
canned cycle
(T series)
Chamfering signal CDZ G053#7 f —
11.8
Chuck/tailstock
barrier (T series)
Tailstock barrier selection signal *TSB G060#7 f —
2.3.4
Butt–type reference
position return
setting
Torque limit reached signals for
butt–type reference position setting
CLRCH1 to CLRCH8 F180 f f
4.6
DNC operation selection signal DNCI G043#5 f f
DNC operation
DNC operation selection confirmation
signal
MRMT F003#4 f f
5.9
Dry run signal DRN G046#7 f f
Dry run
Dry run check signal MDRN F002#7 f f
5.3.2
