Series 0i/0i Mate - Model B Connection manual (Function) Page 813

Connection manual (Function)
B–63833EN–1/02
13. INPUT/OUTPUT OF DATA
795
NE9 Editing of subprograms with program numbers 9000 to 9999
0 : Not inhibited
1 : Inhibited
The following edit operations are disabled:
(1)Program deletion (Even when deletion of all programs is specified,
programs with program numbers 9000 to 9999 are not deleted.)
(2)Program punching (Even when punching of all programs is
specified, programs with program numbers 9000 to 9999 are not
punched.)
(3)Program number search
(4)Program editing after registration
(5)Program registration
(6)Program collation
(7)Displaying programs
Number Message Description
079 PROGRAM VERIFY
ERROR
In memory or program collation,a pro-
gram in memory does not agree with
that read from an external I/O device.
Check both the programs in memory
and those from the external device.
085 COMMUNICATION
ERROR
When entering data in the memory by
using Reader / Puncher interface, an
overrun, parity or framing error was
generated. The number of bits of input
data or setting of baud rate or specifica-
tion No. of I/O unit is incorrect.
086 DR SIGNAL OFF When entering data in the memory by
using Reader / Puncher interface, the
ready signal (DR) of reader / puncher
was turned off.
Power supply of I/O unit is off or cable
is not connected or a P.C.B. is defec-
tive.
087 BUFFER OVERFLOW When entering data in the memory by
using reader /puncher interface,
though the read terminate command is
specified, input does not stop after 10
characters read. I/O unit or P.C.B. is de-
fective.
233 DEVICE BUSY When an attempt was made to use a
unit such as that connected via the
RS–232–C interface, other users were
using it.
239 BP/S ALARM While punching was being performed
with the function for controlling external
I/O units ,background editing was per-
formed.
Alarm and message
Previous page
Next page
