Series 0i/0i Mate - Model B Connection manual (Function) Page 507

Connection manual (Function)

Page of 1090

/ 1090

B–63833EN–1/02

9. SPINDLE SPEED FUNCTION

489

NOTE

The extended specification includes the following two

extensions:

D With the conventional specification, the number of M

codes for specifying a spindle positioning angle is always

6. With the extended specification, an arbitrary number

of such M codes from 1 to 256 can be selected by

parameter setting (See parameter No. 4964.)

D The maximum feedrate for spindle positioning (setting of

parameter No. 1420) can be extended from 240000 to

269000 (unit: 10 deg/min).

IMB When the spindle positioning function is used, semi–fixed angle

positioning based on M codes uses:

0 : Specification A

1 : Specification B

NOTE

In the case of semi–fixed angle positioning based on M

codes, three types of spindle positioning operations can

occur:

(1)The spindle rotation mode is cleared, then the mode is

switched to the spindle positioning mode.

(2)Spindle positioning is performed in the spindle

positioning mode.

(3)The spindle positioning mode is cleared, then the mode

is switched to the spindle rotation mode.

In the case of specification A:

Operations (1) to (3) are specified using separate M

codes.

(1)–Specified using M codes for performing spindle

orientation.

(See parameter No. 4960)

(2)–Specified using M codes for specifying a spindle

positioning angle. (See parameter No. 4962)

(3)–Specified using M codes for clearing spindle positioning

operation. (See parameter No. 4961.)

In the case of specification B:

When M codes for specifying a spindle positioning angle are

specified, operations (1) to (3) are performed successively.

(See parameter No. 4962.)
