B–63833EN–1/02

14. MEASUREMENT

861

(9) Set the tool compensation value writing mode signal GOQSM to “0”.

The writing mode is canceled and the blinking “OFST” indicator light

goes off.

When the tool setter function for a one–turret/two–spindle lathe is in

use, the S1MES or S2MES (spindle under measurement) signal for

the spindle being measured becomes 0.

To use the tool setter function for a one–turret/two–spindle lathe, first

specify the spindle to be measured, using the S2TLS <G040.5> (spindle

measurement select) signal.

(1) Set the tool geometry offset values of each tool in advance.

(2) Execute manual reference position return.

By executing manual reference position return, the machine

coordinate system is established.

The workpiece coordinate system shift amount is computed based on

the machine coordinate system of the tool.

(3) Set the workpiece coordinate system shift amount writing mode

select signal WOQSM to “1”.

The CRT display automatically switches to the workpiece shifting

screen, the “WFST” indicator starts blinking at the status indicator

area in the bottom of the screen, which indicates that the workpiece

coordinate system shift amount writing mode is ready.

When the tool setter function for a one–turret/two–spindle lathe is in

use, the workpiece coordinate system screen is selected, and the

S1MES or S2MES (spindle under measurement) signal, whichever is

applicable, becomes 1.

NOTE

After this, it is impossible to switch the S2TLS (spindle

measurement selection) signal until the WOQSM (offset

write mode) signal becomes 0.

(4) Select a tool to be measured.

(5) Check tool offset numbers.

The tool offset number corresponding to the tool required for

measurement, shall be set in the parameter (No.5020) in advance.

The tool offset number can also be set automatically by setting the

tool offset number input signal (with parameter QNI(No.5005#5)=1).

(6) Manually approach the tool to an end face of the workpiece.

(7) Place the tool edge to the end face (sensor) of the workpiece using

manual handle feed.

When the tool edge contacts the end face of the workpiece, input the

workpiece coordinate system shift amount signal WOSET.

The workpiece coordinate system shift amount on the Z–axis is

automatically set.

(8) Release the tool.

(9) Set the workpiece coordinate system shift amount write mode select

signal WOQSM to “0”.

Basic Procedure to Set

Workpiece Coordinate

Shift Value
