Series 0i/0i Mate - Model B Connection manual (Function) Page 670

Connection manual (Function)
11. PROGRAM COMMAND
B–63833EN–1/02
652
#7 #6 #5 #4 #3 #2 #1 #0
SBV6000 SBM HGO HMC MGO
[Data type] Bit
MGO When a GOTO statement for specifying custom macro control is
executed, a high–speed branch to 20 sequence numbers executed from the
start of the program is:
0 : A high–speed branch is not caused to n sequence numbers from the
start of the executed program.
1 : A high–speed branch is caused to n sequence numbers from the start
of the program.
HMC A custom macro is executed:
0 : At a normal speed.
1 : At a high speed.
NOTE
When this parameter is set, the CNC executes a custom
macro first. For this reason, when this parameter is set,
performance of the following functions may be degraded:
D Screen display of CNC
D Macro executor (excluding execution macros)
HGO When a GOTO statement for specifying custom macro control is
executed:
0 : A high–speed branch is not caused to 30 sequence numbers,
immediately following the point of execution.
1 : A high–speed branch is caused to 30 sequence numbers, immediately
before the point of execution.
SBM Custom macro statement
0: Not stop the single block
1: Stops the single block
If you want to disable the single blocks in custom macro statements using
system variable #3003, set this parameter to 0. If this parameter is set to 1,
the single blocks in custom macro statements cannot be disabled using
system variable #3003. To control single blocks in custom macro
statements using system variable #3003, use bit 7 (SBV) of parameter No.
6000.
NOTE
This bit is invalid when bit 0 (NOP) of parameter No. 6000 is
set to 1. (M series)
Parameter
D Settings for executing
single block stop and
custom macros
