14. MEASUREMENT

B–63833EN–1/02

866

X004

#6 #5

–MIT2

SKIP5

+MIT2

SKIP4

–MIT1

SKIP3

+MIT1

SKIP2

#1 #0

WARNING

Since the same addresses are used for both +MIT1, –MIT1,

+MIT2, –MIT2 and skip signals SKIP2 to SKIP5 (multi–step

skip), be careful when using these two signal types.

GOQSMG039

WOQSM

OFN5

OFN4

OFN3

OFN2

OFN1

OFN0

WOSETG040 S2TLS

F062 S2MES S1MES

3003

#6 #5 #4 #3

DIT

#2 #1 #0

[Data type] Bit

DIT Interlock for each axis direction

0 : Enabled

1 : Disabled

5004

#6 #5 #4 #3

TS1

#2 #1 #0

NOTE

When this parameter is set, the power must be turned off

before operation is continued.

[Data type] Bit

TS1 When the tool offset measurement value direct input B function is used,

touch sensor contact detection is based on:

0 : Four–contact input.

1 : One–contact input.

5005

#6 #5

QNI

#4 #3 #2 #1 #0

[Data type] Bit

QNI The function to input offset value measured B

0 : Does not automatically select the tool offset number

1 : Automatically selects a tool offset number

Signal address

Parameter
