12. DISPLAY/SET/EDIT

B–63833EN–1/02

722

Disabling the current position display is accomplished by setting bit 0

(NDPx) of parameter No. 3115.

Bit 1 (NDAx) of parameter No. 3115 enables the display of positions in

the machine coordinate system.

[Classification] Input signal

[Function] Disables the display of the current position.

A separate signal is provided for each controlled axis. The number at the

end of each signal name denotes the controlled axis number.

NPOS1

⋅⋅⋅1st axis current position display

⋅⋅⋅2nd axis current position display

⋅⋅⋅3rd axis current position display

⋅⋅⋅4th axis current position display

[Operation] When a signal is set to 0, the current position in the corresponding axis

is displayed. When the signal is set to 1, the current position and its

corresponding axis is not displayed.

#7 #6 #5 #4 #3 #2 #1 #0

G198 NPOS4 NPOS3 NPOS2 NPOS1

#7 #6 #5 #4 #3 #2 #1 #0

3115 NDAx NDPx

[Data type] Bit axis

NDPx Display of the current position for each axis

0 : The current position is displayed.

1 : The current position is not displayed.

NDAx Position display using absolute coordinates and relative coordinates is:

0 : Performed.

1 : Not performed. (Machine coordinates are displayed.)

12.1.10

Position Display

Neglect

General

Signal

Position Display Neglect

Signal

NPOS1 to NPOS4<G198>

Signal address

Parameter
