4. REFERENCE POSITION ESTABLISHMENT

183

1005

#6 #5 #4 #3 #2 #1 #0

ZRNx

[Data type] Bit axis

ZRNx When a command specifying the movement (except for G28) is issued in

automatic operation (MEM, RMT, or MDI) before referencing is

completed (after power on)

0 : An alarm is generated. (P/S alarm 224).

1 : No alarm is generated.

1006

#6 #5

ZMIx

#4 #3 #2 #1 #0

NOTE

When this parameter is changed, you must power down the

control before continuing.

[Data type] Bit axis

ZMIx The direction of reference position return

0 : Positive direction

1 : Negative direction

1201

#6 #5 #4 #3 #2

ZCL

#1 #0

[Data type] Bit

ZCL Local coordinate system when the manual reference position return is

performed

0 : The local coordinate system is not canceled.

1 : The local coordinate system is canceled.

1240

Coordinate value of the reference position on each axis in the machine

coordinate system

NOTE

After setting this parameter, turn the power off, then on

again so that the setting will take effect.

[Data type] Two–word axis

[Unit of data]

Increment system IS–A IS–B IS–C Unit

Millimeter machine 0.01 0.001 0.0001 mm

Inch input 0.001 0.0001 0.00001 inch

Rotation axis 0.01 0.001 0.0001 deg
