B–63833EN–1/02

9. SPINDLE SPEED FUNCTION

531

NOTE

This table show an example of three gears. For the basic

spindle motor speed, refer to the spindle motor description

manual. “+ α” means that the spindle motor speed may

slightly exceed the basic spindle motor speed.

If the M type gear selection method is used, use gear change method B

(bit 3 (SGT) of parameter No. 3705 = 1) in the tapping cycle to specify

the following:

The table above shows the maximum low-speed gear speed during rigid

tapping for low-/medium-speed gear change position D (parameter No.

3761).

The table above shows the maximum medium-speed gear speed during

rigid tapping for medium-/high-speed gear change position E (parameter

No. 3762).

If the T type gear selection method is used, add the rigid tapping logic to

the logic programmed in the PMC.

See Section 9.3, “Spindle Control” for details of the spindle gear change

specifications.

The loop gain can be specified for each gear. Specify “0” for parameter

No. 5280 and specify loop gains for each gear for parameter Nos. 5281

to 5284. Unless “0” is specified for parameter No. 5280, the loop gains

for each gear are disabled, and the loop gain common to all gears, the

value of parameter No. 5280, is enabled.

Specify the time constant and the maximum spindle speed for each gear.

Use parameters Nos. 5261 to 5264 to specify the time constant.

Use parameters Nos. 5241 to 5244 to specify the maximum spindle speed.

For M type gear selection method, set the maximum spindle speed to

parameter No. 5243, irrespective of the number of gear stages used.

Setting bit 2 (TDR) of parameter No. 5201 to “1” enables setting of the

time constants used during extraction for each gear set. Specify the

extraction time constant for each gear in parameter Nos. 5271 to 5274.

If bit 1 (VGR) of parameter No. 5200 is set to “1”, the gear ratio for the

spindle and position coder can be set to anywhere between 1:32767 and

32767:1 in one-increment units for three gear sets with 1st spindle of M

series, four gear sets with 1st spindle of T series, or two gear sets with 2nd

spindle. However 1:8 to 8:1 is the recommended value.
