Series 0i/0i Mate - Model B Connection manual (Function) Page 1052

Connection manual (Function)

Page of 1090

/ 1090

B–63833EN–1/02

A. INTERFACE BETWEEN CNC AND PMC

1034

Group

Referen

ce item

series

Address Signal nameSymbol

EGENA F130#4 f f

EGENB F133#4 f f

EGENC

Axis moving signal (PMC axis control)

F136#4 f f

EGEND F139#4 f f

EIALA F130#2 f f

EIALB F133#2 f f

EIALC

Alarm signal (PMC axis control)

F136#2 f f

EIALD F139#2 f f

EID0A to EID31A G146 to G149 f f

EID0B to EID31B G158 to G161 f f

EID0C to EID31C

Axis control data signal (PMC axis control)

G170 to G173 f f

15.1

EID0D to EID31D G182 to G185 f f

EIF0A to EIF15A G144,G145 f f

EIF0B to EIF15B G156,G157 f f

EIF0C to EIF15C

Axis control feedrate signal (PMC axis control)

G168,G169 f f

EIF0D to EIF15D G180,G181 f f

EINPA F130#0 f f

EINPB

F133#0 f f

EINPC

In-position signal (PMC axis control)

F136#0 f f

E EINPD F139#0 f f

EKC0 to EKC7 Key code signal G098 f f

EKENB Key code read completion signal F053#7 f f 15.5

EKSET key code read signal G066#7 f f

ELCKZA G142#1 f f

ELCKZB G154#1 f f

ELCKZC

Accumulated zero check signal

G166#1 f f

ELCKZD G178#1 f f

EM11A to EM48A F132,F142 f f

EM11B to EM48B F135,F145 f f

EM11C to EM48C

Auxiliary function code signal (PMC axis control)

F138,F148 f f

EM11D to EM48D F141,F151 f f

EMBUFA G142#2 f f

15.1

EMBUFB

Buffering disable signal

G154#2 f f

EMBUFC

Buffering disable signal

(PMC axis control)

G166#2 f f

EMBUFD G178#2 f f

EMFA F131#0 f f

EMFB F134#0 f f

EMFC

Auxiliary function strobe signal (PMC axis control)

F137#0 f f

EMFD F140#0 f f
