Series 0i/0i Mate - Model B Connection manual (Function) Page 805

Connection manual (Function)
B–63833EN–1/02
13. INPUT/OUTPUT OF DATA
787
#7
0135
#6 #5 #4 #3 #2 #1 #0
ASC
NOTE
When this parameter is set, the power must be turned off
before operation is continued.
[Data type] Bit
ASC Communication code except NC data
0: ISO code
1: ASCII code
Number Message Description
001 TH PARITY ALARM TH alarm (A character with incorrect
parity was input).
Correct the tape.
002 TV PARITY ALARM TV alarm (The number of characters
in a block is odd). This alarm will be
generated only when the TV check is
effective.
085 COMMUNICATION ER-
ROR
When entering data in the memory by
using Reader / Puncher interface, an
overrun, parity or framing error was
generated. The number of bits of input
data or setting of baud rate or specifi-
cation No. of I/O unit is incorrect.
086 DR SIGNAL OFF When entering data in the memory by
using Reader / Puncher interface, the
ready signal (DR) of reader / puncher
was turned off.
Power supply of I/O unit is off or cable
is not connected or a P.C.B. is defec-
tive.
087 BUFFER OVERFLOW When entering data in the memory by
using Reader / Puncher interface,
though the read terminate command
is specified, input is not interrupted
after 10 characters read. I/O unit or
P.C.B. is defective.
233 DEVICE BUSY When an attempt was made to use a
unit such as that connected via the
RS–232–C interface, other users
were using it.
5227 FILE NOT FOUND A file specified for communication with
the built–in handy file unit is missing.
5228 SAME NAME USED There are duplicate names for files in
the built–in handy file unit.
5229 WRITE PROTECTED A floppy disk in the built–in handy file
unit is write–protected.
Alarm and message
