B–63833EN–1/02

13. INPUT/OUTPUT OF DATA

815

The data input/output function based on the FANUC I/O Link is

implemented by various elements such as ladder programs, I/O Link

assignment, Series 0i/0i Mate parameters, and power mate CNC

parameters. So, problems may occur when the function is started.

The table below lists the symptoms of the problems that may occur,

together with their causes and corresponding corrective actions.

Symptom Cause and corrective action

Data input/output is started, but the

Series 0i/0i Mate and power mate

CNC return no response.

The background is already active (the

background busy signal BGEACT is

set to 1). In this case, the function

cannot be used.

Examples:

1) In MDI mode, the program screen

is selected.

2) Background editing has already

started.

Communication via the RS–232–C

interface is in progress.

Multiple communication operations

cannot be performed at the same

time, such that any subsequent at-

tempt to start the function is ignored.

The selected slave is not a power

mate CNC.

Data input/output function B based on

the I/O Link is not started if the slave

specified with a group number set

with group number specification sig-

nals SRLNI0 to SRLNI3 is other than

a power mate CNC.

A ladder program error may prevent

the function from being started.

Check the ladder program for errors

such as mis–specified addresses.

When an attempt is made to output

data to a power mate CNC:

Series 0i/0i Mate:

OUTPUT blinks con-

Power mate CNC DO signal RPBSY

is not correctly passed to Power Mate

read/write in–progress signal RPBSY

of the Series 0i/0i Mate.

tinuously.

Power mate CNC :

LSK blinks continu-

ously . (Caution)

D Troubleshooting
