A. INTERFACE BETWEEN CNC AND PMC
1022
Function Section
M
series
T
series
AddressSymbolSignal name
SKIP X004#7 f f
Skip function Skip signals
SKIPP G006#6 f —
14.3.1
Start lock signal STLK G007#1 f —
Interlock signal *IT G008#0 f f
Interlock signal for each axis *IT1 to *IT4 G130 f f
Manual feed interlock signal for each
axis and direction
+MIT1, +MIT2 X004#2, #4 f —
Start lock/interlock Manual feed interlock signal for each
axis and direction
–MIT1, –MIT2 X004#3, #5 f —
2.5
Interlock signal for each axis and
+MIT1 to +MIT4 G132#0 to #3 — f
Interlock signal for each axis and
direction
–MIT1 to –MIT4 G134#0 to #3 — f
Cutting block start interlock signal *CSL G008#1 f f
Block start interlock signal *BSL G008#3 f f
Stored stroke limit switching signals in
+EXL1 to +EXL4 G104 f f
Stored stroke limit switching signals in
axis direction
–EXL1 to –EXL4 G105 f f
Stored stroke limit change signal EXLM G007#6 f f
+LM1 to +LM4 G110 — f
Stored stroke check Stroke limit external setting signals
–LM1 to –LM4 G110 — f
2.3.2
Stroke limit release signal RLSOT G007#7 — f
+OT1 to +OT4 F124 — f
Stroke limit reached signals
–OT1 to –OT4 F126 — f
Stored stroke limit
2, 3
Stroke limit 3 release signal RLSOT3 G007#4 f f
2.3.3
Absolute position
Absolute position detector battery
voltage zero alarm signal
PBATZ F172#6 f f
Absolute position
detection
Absolute position detector battery
voltage low alarm signal
PBATL F172#7 f f
1.4.2
Advanced preview Advanced preview control mode signal G08MD F066#0 f f
7.1.11
Software operator’s panel signal (MD1) MD1O F073#0 f f
Software operator’s panel signal (MD2) MD2O F073#1 f f
Software operator’s panel signal (MD4) MD4O F073#2 f f
Software operator’s panel signal (ZRN) ZRNO F073#4 f f
Software operator’s
Software operator’s panel signals
(+J1 to +J4)
+J1O to +J4O
F081#0, #2, #4,
#6
f f
Software operator’s
panel
Software operator’s panel signals
(–J1 to –J4)
–J1O to –J4O
F081#1, #3, #5,
#7
f f
12.1.14
Software operator’s panel signal (RT) RTO F077#6 f f
Software operator’s panel signal
(HS1A)
HS1AO F077#0 f f
Software operator’s panel signal
(HS1B)
HS1BO F077#1 f f
