Series 0i/0i Mate - Model B Connection manual (Function) Page 842
Connection manual (Function)
13. INPUT/OUTPUT OF DATA
B–63833EN–1/02
824
#7
G058
#6 #5 #4 #3
EXWT
#2
EXSTP
#1
EXRD
#0
G091 SRLNI3 SRLNI2 SRLNI1 SRLNI0
#7 #6 #5 #4 #3 #2 #1 #0
G092 BGEN BGIALM BGION IOLS IOLACK
#7 #6 #5 #4 #3 #2 #1 #0
F053 BGEACT RPALM RPBSY
#7 #6 #5 #4 #3 #2 #1 #0
EDGNF177 EPARM EVAR EPRG EWTIO ESTPIO ERDIO IOLINK
#7 #6 #5 #4 #3 #2 #1 #0
F178 SRLNO3 SRLNO2 SRLNO1 SRLNO0
#7 #6 #5 #4 #3 #2 #1 #0
0020 I/O CHANNEL: Selection of an input/output device
This parameter can be set at “Setting Screen.”
[Data type] Byte
[Valid data range] 0 to 35
This CNC provides the following interfaces for data transfer to and from
the host computer and external input/output devices:
– Input/output device interface (RS–232–C serial port 1, 2)
– DNC2 interface
In addition, data can be transferred to and from the power mate CNC via
the FANUC I/O Link. (This parameter need not be set when data
input/output function B based on the I/O Link is used.)
This parameter is used to select the interface used to trnsfer data to and
from an input/output device.
Setting Description
0, 1 RS–232–C serial port (connector JD36A on motherboard)
2 RS–232–C serial port (connector JD36B on motherboard)
5 Data server interface
10 DNC2 interface, OSI–Ethernet
20
Group 0
21
22
Group 1
Group 2
Data is transferred between the CNC and power mate
|
34
|
Group 14
CNC in group n (n: 0 to 15) via the FANUC I/O Link.
34
35
Group 14
Group 15
NOTE
An input/output device can also be selected using the
setting screen. Usually the setting screen is used.
Signal address
Parameter
