[Classification] Output signal
[Function] Notify the PMC of the states of the optional block skip signals BDT1 to
BDT9. Nine signals are provided, corresponding to the nine optional
block skip signals. Signal MBDTn corresponds to signal BDTn.
[Output condition] Signal MBDTn is set to 1 in the following case:
– When the corresponding optional block skip signal (BDTn) is set to 1
Signal MBDTn is set to 0 in the following case:
– When the corresponding optional block skip signal (BDTn) is set to 0
#7 #6 #5 #4 #3 #2 #1 #0
G044
G045
BDT1
BDT9 BDT8 BDT7 BDT6 BDT5 BDT4 BDT3 BDT2
F004
F005
MBDT1
MBDT9 MBDT8 MBDT7 MBDT6 MBDT5 MBDT4 MBDT3 MBDT2
NOTE
1 This function is ignored when programs are loaded into
memory. Blocks containing /n are also stored in memory,
regardless of how the optional block skip signal is set.
Programs stored in memory can be output, regardless of
how the optional block skip signals are set.
Optional block skip is effective even during sequence
number search operation.
2 Position of a slash
A slash (/) must be specified at the head of a block. If a slash
is placed elsewhere, the information from the slash to
immediately before the EOB code is ignored.
3 TV and TH check
When an optional block skip signal is “1”. TH and TV checks
are made for the skipped portions in the same way as when
the optional block skip switch is “0”.
Optional block skip
check signals
MBDT1 <F004#0>
MBDT2 to MBDT9
<F005>
Signal address
Note
