Series 0i/0i Mate - Model B Connection manual (Function) Page 107

Connection manual (Function)

Page of 1090

/ 1090

B–63833EN–1/02

1. AXIS CONTROL

CAUTION

1 Set the same detection unit for both the master and slave

axes.

2 When a manual reference position return is executed,

identical movements are performed along the master and

slave axes until deceleration commences. Subsequently,

grids are detected separately.

3 Pitch error compensation and backlash compensation are

executed separately for the master and slave axes.

4 If control of two master/slave axis pair is specified in

parameter No. 8311, parameters to perform setting for, and

display diagnostic information about, only one master/slave

axis pair are invalid, and if control of only one master/slave

axis pair is specified, parameters to perform setting for, and

display diagnostic information about, only one master/slave

axis pair are valid (except for common parameter Nos. 8311

and 8314).

OPERATOR’S MANUAL

(M series) (B–63844EN)

II.20.1 Simple synchronous control

Series 0i–B

OPERATOR’S MANUAL

(T series) (B–63834EN)

II.18.3 Simple synchronous control

Caution

Reference item
