9. SPINDLE SPEED FUNCTION
586
NOTE
1 To use a varied loop gain on a gear–by–gear basis, set
parameter No.5341 to 0, and set a loop gain for each gear
in parameters No.5342 and No.5343.
2 This parameter is enabled when the SPR parameter (bit 1 of
parameter No.5204) is set to 1.
5350
Positional deviation limit imposed during tapping axis movement in rigid tapping
using the second spindle
[Data type] 2–word
[Unit of data] Detection unit
[Valid data range] 1 to 99999999
This parameter sets a positional deviation limit imposed during tapping
axis movement in rigid tapping using the second spindle.
NOTE
This parameter is enabled when the SPR parameter (bit 1
of parameter No.5204) is set to 1.
5351
Positional deviation limit imposed during spindle movement in rigid tapping using
the second spindle
[Data type] Word
[Unit of data] Detection unit
[Valid data range] 1 to 32767
This parameter is used to set a positional deviation limit imposed during
spindle movement in rigid tapping using the second spindle.
NOTE
This parameter is enabled when the SPR parameter (bit 1
of parameter No.5204) is set to 1.
5352
Positional deviation limit imposed while the tapping axis is stopped in rigid tap-
ping using the second spindle
[Data type] Word
[Unit of data] Detection unit
[Valid data range] 1 to 32767
This parameter is used to set a positional deviation limit imposed while
the tapping axis is stopped in rigid tapping using the second spindle.
NOTE
This parameter is enabled when the SPR parameter (bit 1
of parameter No.5204) is set to 1.
