Series 0i/0i Mate - Model B Connection manual (Function) Page 822

Connection manual (Function)
13. INPUT/OUTPUT OF DATA
B–63833EN–1/02
804
5) Key in a program number.
6) Using soft keys [(OPRT)], continuous–menu key
, [PUNCH], and [EXEC], output the program
corresponding to the keyed–in program number.
· When data input/output function B based on the I/O Link is
used
1) Using the PMC function instruction (WINDW), set the
program number of the program to be output. Specify
–9999 to output all programs.
2) Specify a desired group number with group number
specification signals SRLNI0 to SRLNI3.
3) Select an I/O Link by setting the I/O Link specification
signal IOLS to 1.
4) When external punch start signal EXWT is set to 1, the
program is output to the power mate CNC.
(2) Parameter input/output
A power mate CNC parameter in tape format is stored as a
master–side NC program in a program memory area. The following
program number is assigned to a power mate CNC parameter of
group n:
(Value set in parameter No. 8760) + n
10
(a) Parameter input
· When the data input/output function based on the I/O Link
is used
In step 4) of program input (described in (1).(a)), key in a
program number for a power mate CNC parameter. The
other steps are the same as those for program input.
· When data input/output function B based on the I/O Link is
used
In step 1) of program input (described in (1).(a)), specify a
program number for the power mate CNC parameters. The
remaining steps are the same as those for program input.
(b) Parameter output
· When the data input/output function based on the I/O Link
is used
In step 5) of program output (described in (1).(b)), key in a
program number for a power mate CNC parameter. The
other steps are the same as those for program output.
· When data input/output function B based on the I/O Link is
used
In step 1) of program output (described in (1).(b)), specify
a program number for a power mate CNC parameter. The
remaining steps are the same as those for program output.
(3) Macro variable input/output
In the same way as for parameters, a power mate CNC macro variable
in tape format is stored as a master side NC program in a program
memory area. The following program number is assigned to a power
mate CNC macro variable of group n:
(Value set for parameter No. 8760) + n
10 + 1
