Series 0i/0i Mate - Model B Connection manual (Function) Page 379
Connection manual (Function)
B–63833EN–1/02
7. FEEDRATE CONTROL/ACCELERATION
AND DECELERATION CONTROL
361
Interpolation function f : Can be programmed
: Cannot be programmed
Name
Description
Positioning (G00)
f
Single direction positioning
(G60)
f To perform single direction positioning in the
AI advanced preview control mode, bit 4
(ADP) of parameter No. 7055 must be set to
1.
Exact stop (G09)
f
Exact stop mode (G61)
f
Tapping mode (G63)
f
Linear interpolation (G01)
f
Circular interpolation
(G02, G03)
f (Multiple quadrants allowed)
Dwell (G04) f (For a specified number of seconds or revo-
lutions)
Polar coordinate interpolation
(G12.1, G13.1)
Cylindrical interpolation
(G07.1)
Helical interpolation
(G02, G03)
f (Circular interpolation + Up to two axes for
linear interpolation)
A desired feedrate must be specified by also
taking movement along the helical axis into
consideration.
Thread cutting/synchronous
feed (G33)
Skip function (G31)
f *
High–speed skip function
(G31)
f *
Multistage skip function
(G31 Px)
f *
Reference position return
(G28)
f To execute G28 before reference position
establishment, bit 2 (ALZ) of parameter No.
7055 must be set to 1. *
Reference position return
check (G27)
f *
2nd, 3rd, and 4th reference
position return (G30)
f *
Normal direction control
(G41.1, G42.1)
f Bit 2 (ANM) of parameter No. 5484 must be
set to 1.
Continuous dressing
In–feed control (G161)
Index table indexing
f *
When the index table indexing axis (fourth
axis) is specified for follow–up, bit 7 (NAH4)
of parameter No. 1819 and bit 0 (NMI4) of
parameter No. 7052 must be set to 1.
