3.CREATING AND EDITING SEQUENCE PROGRAMS B-66234EN/05

- 84 -

NOTE

1 If the number of contacts and coils per row is

changed, a ladder diagram in the edit window and

clipboard is deleted, and reediting is disabled.

2 A net that has more relays or coils than the set

number of contacts and coils is displayed as a

continuation net as conventionally done.

1-2 ToolTips

When the pointer is positioned to a basic instruction in a

ladder diagram, the information such as the address, the

symbol and the comment is displayed. Tool tip is displayed

when checked.

1-3 Grid

Specifies that grid lines are displayed on the ladder diagram.

It is displayed when checked.

1-4 Editing ladder diagram on display window

Specifies that the ladder diagram is edited in the display

window. The display and editing of a ladder diagram are

possible in one window when checking.

1-5 Always display a window

Specifies that the ladder diagram editing window is always

displayed. Multiple Ladder windows can be displayed at the

same time when checked.

1-6 Undo max number

The operation of you in the ladder editing screen can be

restored. The maximum number of the operations (Ctrl+Z)

to restore is specified.

1-7 Search using the address/symbol on cursor

You can specify the way of the search by the soft key, and

the search by the context menu in the ladder edit display.

When there is no check of this item, you can search by F3

key in the online monitor. The search condition is set up in

the search screen.

1-8 Show comment of contact

Select the comment which you want to display as the

comment of contact in ladder edit display. When the

comment is 4 sets, the comment of status bar can be

specified by this item.

1-9 Show comment of Coil

Select the comment which you want to display as the

comment of coil in ladder edit display.
