FANUC LADDER-III

SUPPLEMENTARY OPERATOR’S MANUAL

01 05/05/30 First issue B-66234EN/05-3

EDIT

DATE

DESIG.

DESCRIPTION

49/55

TITLE

DRAW.NO.

SHEET

CUST.

Example of trace result output (For view comfort, tab settings are made in several places. In actual

data output, however, no tab settings are made.)

‘PMC TRACE DATA’

‘Edition’, 1

‘Setting’, , ,

1,‘Sampling mode’, 2, ‘SIGNAL TRANSITION’

2,‘Sampling resolution’, 8, ‘MSEC’

3,‘Sampling time’, 2000,

4,‘Stop condition’, 3, ‘TRIGGER’

5,‘Stop trigger address’, ‘X10.0’, ‘SYMBOL1’

6,‘Stop trigger mode’, 1, ‘RISING EDGE’

7,‘Stop trigger position’, 50(1250/2500), ‘%’

8,‘Sampling condition’, 1, ‘TRIGGER’

9,‘Sampling trigger address’, ‘X10.1’, ‘SYMBOL2’

10,‘Sampling trigger mode’, 3, ‘BOTH EDGE’

‘Address’,‘R0000.0’, ‘R0000.1’, ‘R0000.2’, ‘R0000.3’, ‘R0000.4’, ‘R0000.5’,

‘R0000.6’, ‘R0000.7’, ‘R0001.0’, R0002.0’

‘Symbol’, ‘ZRN_M’ , , , ‘*SPA1’ , ‘*SPA2’, ‘MX-RD’,‘RSTN’, ‘RSTMA’,

‘MO1X’, ‘MO2X’

‘Comment’, ‘ZRN MODE’, ’TIME CNT.AUX1(MEM)’ , , , , ‘READ

STROBE’, ‘NORMAL RESET PB’, ‘INIT_M&RSTM (RST->MACRO)’,

‘OPTIONAL STOP1’,’OPTIONAL STOP2’

‘Check’, 0, 1, 1, 1, 1, 1, 0, 1, 1, 1

‘Data’,‘R0000.0’, ‘R0000.1’, ‘R0000.2’, ‘R0000.3’, ‘R0000.4’, ‘R0000.5’,

‘R0000.6’, ‘R0000.7’, ‘R0001.0’, ‘R0002.0’

-6, 1,0,0,0,0,0,0,0,0,0

-5, 0,0,0,0,0,1,1,1,1,1

-4, 1,1,1,1,1,0,0,0,0,0

-3, 0,1,0,1,0,1,0,1,0,1

-2, 0,0,1,1,0,0,1,1,0,0

-1, 1,1,0,0,0,0,1,1,1,1

0, 1,1,1,1,1,1,1,1,1,1

1, 0,0,0,0,0,0,0,0,0,0

2, 1,0,0,0,0,0,0,0,0,0

3, 0,0,0,0,0,1,1,1,1,1

4, 1,1,1,1,1,0,0,0,0,0

NOTE
