Toolbar
(1) (2) (3) (4) (5) (6)
Fig. 3.19.1(f)
(1) Zoom-in button
Magnifies ladder diagrams.
(2) Zoom-out button
Reduces (shrinks) ladder diagrams.
(3) Resize button
The size of the ladder diagram is fitted to the window.
(4) Ladder display form
Specify the display form of the ladder diagram. "Ladder display form"
changes depending on the comparison mode.
Comparison mode Ladder display form
Address and symbol are
comparative targets
"Address & symbol"
Do not compare symbol "Address"
Do not compare address, if
symbol exists
"Symbol"
(5) Jumping to the previous different point.
The upper different part is searched and displayed.
(6) Jumping to the next different point.
The lower different part is searched and displayed.
Notes
1. When step sequence programs are compared, only the address is compared. You can confirm
existence of the differences by the number of different net count and the background color, although the
detailed screen is not opened.
2. When you compared the step sequence with the ladder, the difference is displayed as "*" and the
detailed screen cannot be opened.
3. When you specify the range of the comparison, only the subprograms within the range on the list screen
are displayed.
4. When setting the display color to 256 colors, the changes, the additions and the deletions are displayed
in gray. In this case, please change the color setting of the option screen. Setting High Color or more (16
bits) is recommended.
5. To display the differences with the ladder in CNC, please convert the ladder in CNC into the LAD file by
using an online function and the import function. Afterwards, please display the difference by using this
function.
6. This function cannot be used in the online mode. Please change to the offline.
7. This function displays the difference of each net.
Previous page
Next page
