B-66234EN/05 13.ERROR MESSAGES

- 459 -

Error code Message Cause/action

J: W-7204

The paragraph of comment exceeded the

number of limitations.(Prog.:$, Symbol:$)

J: W-7205

The comment has exceeded the limitation

length of characters.(Comment)

J: W-7206

The comment used the limitation

character.(Comment)

J: W-7210 Address and type does not exist.

J: W-7211

This symbol cannot be defined as the local

symbol.(Prog., Symbol, Address)

J: W-7212

The symbol of the same name as the already

inputted global symbol cannot be

inputted.(Prog., Symbol)"

J: W-7213

The symbol of the same name as the already

inputted local symbol cannot be

inputted.(Prog., symbol)

J: W-7214 Prog. is illegal.(Prog.)

J: W-7215 Attribute is illegal.(Attribute)

J: W-7216

Address and Attribute are

contradictory.(Address, Attribute)

J: W-7217

Address and Type are contradictory.(Address,

Type)

J: W-7218 Type does not exist.

J: W-7219 Type is illegal.(Type)

13.2.10 Mnemonic Conversion

Error code Message Cause/action

K:F-2000 Insufficient memory.

K:F-2001 Insufficient disk space.

K:F-2006 Not found **** file.

K:F-2100 Not found * file.

K:F-2101 Set-up file broken.

K:F-2102 Illegal option(s).

K:F-2103 Insufficient parameter(s). System parameter /function instruction data is insufficient.

K:F-2104 Too many parameters. Too many parameters are specified in a function instruction.

K:F-2105 Illegal Option-specified file.

K:F-2106 Illegal Idcode.

K:F-2107 Expected terminator.

K:F-2108 PMC series is different from Source-program.

K:F-2109 Expected Idcode.

K:F-2110 Illegal parameter(s).

K:F-2111 Create temporary file(s) in current directory.

K:F-2112 Not specified environmental variable 'TMP'.

K:F-2113 Illegal name of Set-up file.

K:F-2114 Not found Set-up file.

K:F-2115 Expected '/PC' option.

K:F-2116 **** executable file not found.

K:F-2117 Input data illegal.

K:F-5001 Prog. is illegal.(Prog.)

K:F-5002 Prog. is out of range.(Prog.)
