1.SETUP B-66234EN/05

- 2 -

1.1 OPERATING ENVIRONMENT

The operating environment required for this software is as follows:

• Computer

PC/AT-compatible computer running Windows 98 SE, NT4.0,

2000, Me, or XP (English/Japanese system)

• CPU

Pentium 133 MHz or better

• Memory

For Windows 98 SE

⋅ 16MB or more (32MB or more recommended)

For Windows NT 4.0

⋅ 24M or more (32MB or more recommended)

For Windows 2000, Me, or XP

⋅ 32MB or more (64MB or more recommended)

• Hard disk

20MB of free space required (at installation)

100MB of free space required (at execution)

NOTE

1 Time required for ladder diagram editing and

processing of symbols and net comments is

affected by the free spaces of memory and the

hard disk. When handling a source program

including many ladders, symbols, comments, or net

comments or editing ladder diagrams on multiple

screens, allocate much more free spaces as far as

possible.

2 We recommend that FANUC LADDER-III be run

under Windows 98 SE, Windows NT 4.0, Windows

2000, Windows Me, or Windows XP.
