3.CREATING AND EDITING SEQUENCE PROGRAMS B-66234EN/05

- 148 -

3.8.4 New Line Character, Numeric Data

The input method of New line character and Numeric data is decided

according to the input mode and the content of MSG_EDIT_VAL (the

setting in “%%%flset.cnf” file).

• The setting of MSG_EDIT_VAL in “%%%flset.cnf” file.

• Input method of New line character

New line character

Input mode MSG_EDIT_VAL

Input Display

<Enter> key or @0A@ | Japanese-language

input mode

<Enter> key •

@0A@ @0A@

Code input mode

@0A@ @0A@

;==============================================================================

; FANUC LADDER-III Initial Setting File

; ( `key word =' <= 9characters )

;==============================================================================

;

~~~~~;

*S; ======== System Setup ========

~~~~~;

;

exparam=0;

;

LAD_FILE_COUNT=10

;

MSG_EDIT_VAL=1 Set ‘0’ or ‘1’(default) by the text editor.

;

~~~~~

%%%

ET.
