B-66234EN/05 APPENDIX E.DATA FORMAT OF THE EXTERNAL SYMBOL FILE

- 495 -

The contents of option when Output

The identification code of the external symbol file is decided by

existence of specification of an extended function.

• In 30i/31i/32i-A

Table E.1(b)

Identification code

%@2-E(SYM=1 ADR=2 CM1=3 CM2=4)

(Example output)

The symbol is the 1st row, the address is the 2nd row, the

comment1 is the 3rd row and the comment2 is outputted to

the 4th row.

%@2-E(SYM=1 ADR=2 CM1=3 CM2=4)

STOP,Y0.0,Output Line No.43,Stop signal on

POWER_OFF,X32.0,Input Line No.183,Power off status

DOOR,X32.1,Input Line No.184,Safety door open

• In 30i/31i/32i-A Extended function

Table E.1(c)

Identification code

%@2-E(SYM=1 SCP=2 TYP=3 ADR=4 CM1=5 CM2=6 CM3=7

CM4=8)

(Example output)

The symbol is the 1st row, the address is the 2nd row, the

type is the 3rd row, the program is the 4th row, the

comment1 is the 5th row and and the comment2 is outputted

to the 6th row.

%@2-E(SYM=1 ADR=2 TYP=3 SCP=4 CM1=5 CM2=6)

STOP,Y0.0,BOOL,,Output Line No.43,Stop signal on

POWER_OFF,X32.0,BOOL,,Input Line No.183,Power off status

DOOR,X32.1,BOOL,,Input Line No.184,Safety door open
