B-66234EN/05 APPENDIX D.MULTI-LANGUAGE PMC MESSAGE CREATION TOOL

- 489 -

[Example –1]

Create a multi-language PMC message file “msg_mcard” from a

source file “multi_msg.txt”.

- Command

[Example –2]

Create a multi-language PMC message file of 2nd-path PMC from

source files divided by a language.

Command

Multi-language message text file (ANSI)

(multi_msg.txt)

%@4-D

“Create：11-Dec-2003 Edition：0002

Multi-language message English / German / Japanese”

“English message”

$0 ALM1001 1001 FUSE IS BLOWN (SURGE KILLER)

$0 %A000.1 1002 EXT. EMERGENCY STOP SIGNAL ON

$0 LEVEL1.ALM1003 1003.TIME OVER (M100-M109)

“German message”

$2 ALM1001 1001 FUSEIS BLOWN (SURGE KILLER)

$2 %A000.1 1002 EXT. EMERGENCY STOP SIGNAL

$2 LEVEL1.ALM1003 1003 TIME @0DB101@VER (M100-M109)

“Japanese message”

$1 ALM1001 1001 ﾋｭｰｽﾞ切れ(ｻｰｼﾞｷﾗｰ)

$1 %A000.1 1002 外部非常停止になりました

$1 LEVEL1.ALM1003 1003 ﾀｲﾑｵｰﾊﾞｰ (M100-M109)

English message text file (ANSI)

%@4-D

$0 ALM1001 1001 FUSE IS BLOWN (SURGE KILLER)

$0 %A000.1 1002 EXT. EMERGENCY STOP SIGNAL ON

$0 %P7.ALM1003 1003.TIME OVER (M100-M109)

German message text file (Unicode)

%@4-D

$2 ALM1001 1001 FUSEIS BLOWN (SURGE KILLER)

$2 %A000.1 1002 EXT. EMERGENCY STOP SIGNAL ON

$2 %P7.ALM1003 1003 TIME ÕVER (M100-M109)

Japanese message text file (ANSI(SHIFT-JIS))

%@4-D

$1 ALM1001 1001 ﾋｭｰｽﾞ切れ(ｻｰｼﾞｷﾗｰ)

$1 %A000.1 1002 外部非常停止になりました

$1 %P7.ALM1003 1003 ﾀｲﾑｵｰﾊﾞｰ (M100-M109)

2nd-path PMC

multi-language

PMC message file

(msg_mcard)

 cd \pmc_message

 fmsgcnv multi_msg.txt /o=msg_mcard



 cd \pmc_message

 fmsgcnv engmsg.txt + germsg.txt + jpnmsg.txt /p=2

/o=msg_mcard



1st-path PMC

multi-language

PMC message file

(msg_mcard)
