6.MNEMONIC EDITING B-66234EN/05
- 250 -
Control character
In a mnemonic file, a dollar sign “$” is used as the control character.
When a dollar sign is used in a string, describe “$$.”
(1) Symbol and comment data
• Specifying address and symbol
Describe an address and symbol on the same line. At the
beginning of a line, describe an address, use a half-size
space or tab as a delimiter, and then describe a symbol.
R0200.0
UNIT-3-POWER
• Specifying a relay comment and coil comment
Describe a relay comment and coil comment after the
specification of an address described in (1). A string
enclosed in the first single quotation marks “ ' “ after “$1” is
a relay comment. A string enclosed in the second single
quotation marks is a coil comment.
$1
’KEEPPOWERON’ ’KEEPPOWERON’
When you do not use a relay comment, describe a pair of
single quotation marks for the relay comment part.
$1 ’’ ’INITIALIZE OF SEQUENCE’
• Specifying the multiple comments
Describe a comment for multi-language display after the
specification of an address described in (1). A string
enclosed in the first single quotation marks “ ' “ after “$1” is
1st comment. A string enclosed in the second single
quotation marks is 2nd comment.
$1
’KEEPPOWERON’ ’KEEPPOWERON’
When you do not use 1st comment, describe a pair of single
quotation marks for the 1st comment part.
$1 ’’ ’INITIALIZE OF SEQUENCE’
Half-size space or tab
A
ddress
Symbol
Half-size space or tab
Relay comment
Coil comment
Half-size space or tab
Mark that represents comment data (always '$1')
Half-size space or tab
1st comment
2nd comment
Half-size space or tab
Mark that represents comment data (always '$1')
