B-66234EN/05 13.ERROR MESSAGES

- 465 -

Error code Message Cause/action

K:W-4143

The symbol replaced by the specified character

was not output because it was duplication

definition.

K: W-7000

The space code of the symbol data was

replaced with the specification character.

The white-space character of a symbol was replaced with

the specified character.

K:W-7001

This symbol cannot be defined as the local

symbol.(Symbol, Address)

K:W-7002 The space code exists in the symbol data.

K:W-7003

The symbol of the same name as the already

inputted local symbol cannot be

inputted.(Prog., symbol)

K:W-7004 Too long strings for third comment data.

K:W-7005 Too long strings for fourth comment data.

K:W-7006 Third comment data already exist.

K:W-7007 Fourth comment data already exist..

K:W-7008 It skipped because there was no symbol.

K:W-7009

The symbol that used the limitation character

was skipped.(Prog., Symbol)

K:W-7010

The symbol that used the limitation character

was replaced.(Prog., Symbol)

K:W-7011 Address and Type does not exist.

K:W-7012 Type is illegal.(Type)

K:W-7013

Address and Type are contradictory.(Address,

Type)

K:W-7014 Address or Type is illegal.(Address, Type)"

K:W-7015 Type was changed to LABEL.

K:W-7016 Type cannot be changed.

K:W-7017 Type was changed to PROG.

K: W-7018 Address is illegal. Confirm the address and change into the right address.

K: W-7019 Address and Symbol type is undefined. Confirm the type of the address and the symbol and change

into the right address or the right type.

K: W-7020 The quotation mark is not a pair. Confirm the quotation mark (the double quotation mark or

the single quotation mark).

K: W-7021 Address is undefined. Add the address.

K:W-7201 The undefined symbol is used.

13.2.11 Input/Output

Error code Message Cause/action

L:E-6000 I/O Error. Recheck the setting of MONIT on the PMC.

L:E-6001 The system failed in making the thread

L:E-6002 PMC parameter file read error

L:E-6003 PMC parameter file write error

L:E-6004

PMC parameter file write error Insufficient disk

space

L:E-6005

This file format is not PMC parameter file

format

L:E-6006

Can not load PMC parameter from PMC

side(Not EDIT mode)

L:E-6007

Can not store PMC parameter to PMC side(Not

emergency stop nor PWE = 1)
