B.CONVERSION USING A SIGNAL ADDRESS CONVERTER APPENDIX B-66234EN/05

- 470 -

B CONVERSION USING A SIGNAL

ADDRESS CONVERTER

Table B

Converter file name Applicable function Reference document

FS0T_CNV.SYM

PMC-L/M/M(MMC)

(FS0-T)

→

PMC-SA1/SA3/SB3/SC3/

SB4/SC4/SB5/SB6

(FS16/18/20-T)

FS0M_CNV.SYM

PMC-L/M/M(MMC)

(FS0-M)

→

PMC-SA1/SA3/SB3/SC3/

SB4/SC4/SB5/SB6

(FS16/18/20-M)

PM-C_CNV.SYM

PMC-P

(Power Mate-MODEL C)

→

PMC-PA3

(Power Mate-MODEL D/F/H)

FANUC PMC-MODEL

PA1/PA3/SA1/SA2/SA3/SA5/

SB/SB2/SB3/SB4/SB5/SB6/

SB7/SC/SC3/SC4/NB/NB2/

NB6

Programming Manual

(Ladder Language)

B-61863E

The converter files are stored in the subdirectory \APPENDIX

of the system floppy (Vol. 5).

Example of operation: PMC-P → PMC-PA3

<1> By using FANUC LADDER, convert a program of the PMC-P

model (conversion source) to a mnemonic file. (A in the figure

below)

<2> By using FANUC LADDER-III, create a program of the

PMC-PA3 model (conversion destination).

<3> Convert the program of <2> to mnemonics. (B in the figure

below)

<4> Start a text editor commercially available, then open the

mnemonic file (conversion destination) created in <3>.

<5> Replace the symbol data of the mnemonic file (conversion

destination) with the converter file. (C in the figure below)

<6> Replace the ladder data of the mnemonic file (conversion

destination) with the ladder data of the mnemonic file

(conversion source) created in <1>. (D in the figure below)

<7> Close the mnemonic file (conversion destination) on the text

editor.

<8> By using FANUC LADDER-III, convert the mnemonic file

(conversion destination) of <7> to a source program (with the

program created in <2> left open).

<9> Delete all symbol comment data.
