10.COMMAND LINE EXECUTION FUNCTION B-66234EN/05

- 380 -

10.5 SAMPLE COMMAND FILE

An example of programming a command file is shown below.

Example)

<1> Opens ladder program D:\SB6_LAD\SB6_A.LAD.

<2> Imports source program D:\LAD_SRC\LEVEL1.#LA.

<3> Imports source program D:\LAD_SRC\LEVEL2.#LA.

<4> Imports source program D:\LAD_SRC\P15.#LA.

<5> Imports symbol and comment source program

D:\SYMBOL_SRC\XSYMBOL.000.

<6> Executes compilation in condense mode with the symbol and

comment output option specified.

<7> Exports the ladder program to memory card format file

D:\SB6_MEM\SB6_A.MEM.

<8> Saves the ladder program into D:\SB6_LAD\SB6_A.LAD and

closes it.

<9> Terminates batch processing.

Specify the command procedure for the above processing as follows:

;===========================================

; FANUC LADDER-III Batch Command File

;===========================================

FlOpen D:\SB6_LAD\SB6_A.LAD

Import /Ladder=

LEVEL1 D:\LAD_SRC

Import /Ladder=

LEVEL2 D:\LAD_SRC

Import /Ladder=P15 D:\LAD_SRC

Import /Symbol D:\SYMBOL_SRC

Compile /condense=1 /symbol=1

Export /MemData D:\MEMCARD\SB6_A.MEM

FlClose

End

;

10.6 NOTE

If an invalid command or nonexistent file or file folder is specified,

processing stops at the point where the invalid item is found.
