3. Click <Exec> button. Then, the compilation is executed.
4.1. Command Line Execution Function
The parameter was added in relation to addition of the compilation option item.
"10.4.3 Compiling an *.LAD File" is updated.
When the multiple comments are unsupported PMC
Compile [/condense=0 | 1] [/symbol=0 | 1] [/longsym=0 | 1] ] [/comment=0 | 1] [/netcmt=0 | 1]
[/multi=0 | 1] [/warning=0 | 1] [/password=0 | 1 | 2 | 3 [string1] [string2]] [/lang=0 | 1]
- Parameter
/condense =0:
Compiles the file not in the condense mode.
=1:
Compiles the file in the condense mode.
/symbol =0:
Outputs neither symbols nor comments.
=1:
Outputs symbols and comments.
* This parameter is /symbol=1 when omitted.
/longsym =0:
Does not ignore too long strings of symbols.
=1:
Ignores too long strings of symbols.
/comment =0:
Outputs no coil comments.
=1:
Outputs coil comments.
* This parameter is /comment=1 when omitted.
/netcmt =0:
Outputs no net comment pointers.
=1:
Outputs net comment pointers.
/multi =0:
Does not check function parameter numbers for duplication.
=1:
Checks function parameter numbers for duplication.
/warning =0:
Does not output details of warning.
=1:
Outputs details of warning. Warning number: I:W-4500, I:W-4501
* This parameter is /warning=1 when omitted.
/password =0:
Sets no passwords.
=1:
Sets a password to permit display and a password to permit display and editing.
=2:
Sets a password to permit display and editing.
=3:
Sets a password to permit display.
string1: String of a password to permit display (up to 8 characters)
string2: String of a password to permit display and editing (up to 8 characters)
/lang =0:
Use English as the coil comment language.
=1:
Use Japanese as the coil comment language.
