FAPT Ladder-III Operators manual Page 481

Operators manual

Page of 714

/ 714

B-66234EN/05 13.ERROR MESSAGES

- 455 -

Error code Message Cause/action

I:E-3600 Data too large.(LADDER + step sequence)

The total size of the ladders and step sequences exceeded

the maximum allowable value of a selected type of

program. Reduce the size of the ladders/step sequences.

I:E-3601

Data too large.(message + symbol + comment

+ LADDER + step sequence)

The total size of the messages, symbols, comments,

ladders, and step sequences exceeded the maximum

allowable value of a selected type of program. Reduce the

amount of data.

I:E-3620 There is no subprogram ****.

Because the sub-program file with number **** is not

included in the selected program, the file cannot be called.

Create a sub-program with number ****.

A sub-program exists, but the END instruction is specified

at the end of level 2.

I:E-3640

LADDER/step sequence program exists

beyond END instruction.

The END instruction is specified at the end of a

sub-program, but a sub-program with a greater program

number exists.

I:E-3650 There is no label of ****.

Label **** representing the jump destination of the JMPC

instruction cannot be found.

I:E-3651 The label of **** is used twice or more.

In the main program, the same label number **** is defined

as the jump destination of the LBL instruction. Define a

different label number.

I:E-3652 Too many labels.

The total number of LBL instruction jump destinations

defined in the main program exceeded the maximum

allowable value of a selected type of program. Reduce the

number of jump destinations defined.

I:E-3653 The label of **** to refer exists in another level.

JMPC is the instruction for making a jump from a

sub-program to the second level of the main program.

Define the jump destination label **** at the second level.

I:E-3654

The label of **** exists in the range of the COM

instruction.

The jump destination label **** of the JMPC instruction is

specified within a COM instruction control range. Specify

the label **** outside the control range.

I: E-6270 CS instruction can not be used excluding the

2nd level main program.

Use functional instruction CS in the LEVEL2 or the

subprogram.

I: E-6271 CM instruction can not be used excluding the

2nd level main program.

Use functional instruction CM in the LEVEL2 or the

subprogram.

I: E-6272 CE instruction can not be used excluding the

2nd level main program.

Use functional instruction CE in the LEVEL2 or the

subprogram.

I: E-6330 CS instruction can not be used in the range

controlled COM instruction.

Do not use functional instruction CS between COM and

COME.

I: E-6331 CM instruction can not be used in the range

controlled COM instruction.

Do not use functional instruction CM between COM and

COME.

I: E-6332 CE instruction can not be used in the range

controlled COM instruction.

Do not use functional instruction CE between COM and

COME.

I: E-6360 There is no CE instruction. Although the functional instruction CS is used, there is no

functional instruction CE that means the end.

I: E-6361 Another CS instruction can not be used in the

range of CS instruction.

Use CS and CE in a pair. And don’t nest a pair of CS

and CE.

I: E-6362 CM instruction must be used between CS and

CE instruction.

Use functional instruction CM between CS and CE

I: E-6363 CE instruction must be used in CS instruction

and a pair.

Use CS and CE in a pair. And don’t nest a pair of CS

and CE.

I: E-6365 Use only CM instruction between CS and CE

instruction.

Do not use other instructions except the functional

instruction CM between CS and CE.

I: E-6751 File I/O error.
