6.MNEMONIC EDITING B-66234EN/05

- 266 -

6.5 CONVERTING STEP SEQUENCE PROGRAMS TO

MNEMONIC FILES

This section describes the procedure for converting a step sequence

program to a mnemonic file. Use this function only when you change

a conventional model to a new model.

Procedure

1. Modify a mnemonic option definition in the %%%FLSET file in

the FANUC LADDER-III installation folder, using a text editor.

;==============================================================================

; FANUC LADDER-III Initial Setting File

; ( `key word =' <= 9characters )

;==============================================================================

;

～～

*M; ======== Mnemonic options definition ========

;

P_G_COMPATIBLE = /ERC FLMNE.ERR /OUT V /P-G

JPN_COMMENT = /ERC FLMNE.ERR /OUT V /SJ /MJJ /ICH

JPN_FULL_OPTIONS = /ERC FLMNE.ERR /OUT V /LX 8 20 28 /SJ /LS /LC /LF /LN /MJJ /ICH

ENG_FULL_OPTIONS = /ERC FLMNE.ERR /OUT V /LX 8 20 28 /LS /LC /LF /LN /ICH

JPN_LABEL_SUBPRG = /ERC FLMNE.ERR /OUT V /LX 10 21 31 /SJ /LAD /LC /LLS /LAS /LS /LFN /MJJ /ICH

ENG_LABEL_SUBPRG = /ERC FLMNE.ERR /OUT V /LX 10 21 31 /LAD /LC /LLS /LAS /LS /LFN /ICH

;

SFC=1; ← When you want to convert a step sequence program to a mnemonic file or source program, set 1.

;

2. Select [Tool] - [Mnemonic Convert...]. The [Mnemonic] dialog

box appears. In this dialog box, convert a step sequence program

to a mnemonic file.

NOTE

1 Do not edit a step sequence program converted to

a mnemonic file using a text editor.

2 If you re-install the FANUC LADDER-III, the content

of “%%%FLSET” file is replaced with initial value.
