B-62994EN/02 5. NC PROGRAM

-91-

Procedure

1. If the soft key is currently not displayed, press the function

selection key .

2. Press the soft key.

3. If the [Program Directory] screen is currently not displayed, press the

chapter selection key .

Press the soft key.

The [Program Directory] screen appears.

NOTE (Continued)

u Background editing (A program other than the selected program

can be created, edited, and deleted.)

FS16/18/21, Power Mate, NC Board

l Operation

• Reset in EDIT mode or MDI mode

• P/S alarm 000 (PLEASE TURN OFF POWER) and P/S

alarm 101 (PLEASE CLEAR MEMORY) already released

l Protect key

• Released

For an explanation of how to release the protect key, refer to the

manual supplied by the machine tool builder.

To change the CNC operating mode from the software operator's

panel, see Section 6.7, "Software Operator's Panel Settings."
