B-62994EN/02 1. SETUP

-5-

•• Installing the non-English message environment

1. Insert the disk (A02B-0207-K750#ZZ07-5) into the floppy disk

drive.

2. Click the [Start] button.

3. Select [Run].

4. Enter the data corresponding tohe target language as listed below,

then click the <OK> button.

Japanese <drive-name> : \JPN\ADDLANG

German <drive-name> : \GER\ADDLANG

French <drive-name> : \FRE\ADDLANG

Italian <drive-name> : \ITA\ADDLANG

Spanish <drive-name> : \SPA\ADDLANG

<drive-name> is the name of the 3.5-inch floppy disk drive.

5. Perform installation according to the displayed messages.

ll WIN16 version

•• Installing Basic Operation Package 1

1. Insert the disk (A02B-0207-K750#ZZ07-8) into the floppy disk

drive.

2. Click the [Start] button.

(For Windows 3.1, select [File].)

3. Select [Run].

4. Enter <drive-name>:SETUP, then click the <OK> button. (<drive-

name> is the name of the 3.5-inch floppy disk drive.)

5. Perform installation according to the displayed messages.

6. Upon the completion of installation, restart the personal computer.

The setup program of Basic Operation Package 1 installs the English

version by default. To display non-English messages (Japanese,

German, French, Italian, or Spanish), subsequently install the non-

English message environment, as follows.

NOTE

Before installing the Japanese message environment, start and

terminate Basic Operation Package 1 at least once. For an

explanation of how to start and terminate Basic Operation

Package 1, see Section 2.1, "Starting and Terminating Basic

Operation Package 1."

Non-English messages can be displayed only under Windows of

the target language version. For example, Japanese messages

can be displayed only under Japanese Windows and German

messages can be displayed only under German Windows.
